AEK / Economizer

Vertical Tabs

General

• Aralsan Economizer is used for preheating of boiler feed water with flue gas to recover its energy

Capacity Range

• The capacity of economizer is selected according to boiler capacity and flue gas temperature wher economizer is installed.
• Please send us your boiler capacity, fuel type and flue gas temperature to determine economizer capacity

Standard Operation Accessories

• Economizer body
• Control panel (It is placed in boiler control panel if Aralsan boiler is used)
• Nice operation instructiun on anodized aluminum
• Flue gas inlet, outlet and by-pass flaps
• Flap control motor
• Water stop valves
• Drainage valve
• Pressure controller
• Pressure gauge
• Water inlet and outlet temperature controllers and indicators
• Flue gas inlet and outlet temperature controllers and indicators

Standard Safety Accessories

• Safety valve
• Safety pressure controller
• Safety temperature controller
• Motor over load protection relay
• Alarm light and buzzer

Manufacturing features

• Installed horizontal or vertical position
• Manufactured with high quality  certified seamless tinned tubes
• All weldings are made by welders certified in accordance with EN 9606-1
• All weldings are controlled by NDT technicians and UT test is applied to a certain percentage of them
• Whole body is painted double coat with heat resistant paint
• Insulated with rock wool and covered color galvanized sheet
• Ceramic gasket is used for door and covers sealings against gas leakage
• ARALSAN's warranty extendable up to 5 years
